FEATURES
American Dynamics now offers 15 and 17-inch
LCD flat panel monitors designed for
demanding security professionals. These
monitors provide high resolution display of
computer or motion video signals via multiple
inputs. Using bright, active matrix displays
offering up to 1280 x 1024 resolution, these
monitors can be used for any computer
application or as direct replacements for
conventional CRT security monitors.
Both monitors are able to automatically detect
and display all inputs, including composite
NTSC/PAL video or computer signals. Using
universal power supplies at 100/240 VAC, these
monitors also offer looping inputs for S-Video
(Y/C) or BNC type connections.
Looping audio connectors are also included in
easy access locations on the back panel of each
monitor. Offering integrated power supplies
and detachable bases, these monitors include
VESA compliant mounting holes and can be
easily adapted to the available wall or pole
mounts.
• N TSC/PAL auto detect
• V GA (D-sub), and
looping S-VHS (Y/C),
BNC (composite video)
connectors
• R CA-connector looping
audio
• D etachable desk base
stand included
• S upport up to
1280 x 1024 resolution
(ADMNM1LCD17),
1024 x 768 resolution
(ADMNM1LCD15)
• Auto brightness
• C ontrast ratio up
to 400:1
• S peakers included
• L ow power consumption
(45 watts)
• 1 00/240 VAC 60/50 Hz
universal power supply
• L ooping audio
www.americandynamics.net
Front side – Single sheet – Letter size – print 4/c
15 and 17-inch CCTV
Flat Panel Monitors
WITH MULTI - MODE INPUTS
