Dr231, Rear panel – Yokogawa DR240 User Manual

Page 248

background image

14-21

IM DR231-01E

Specifications

14

DR231

438

30

207

98.8

266

25

424

Rear Panel

Unit : mm

If not specified, the tolerance is

±3%. However, in cases of less than 10mm, the tolerance is ±0.3mm.

AC power supply model

DC power supply model

AC power supply model

DC power supply model

30

252

98.8

14.3 Dimensional Drawings
