Yokogawa DA100 User Manual
Page 16
IM DA100-01E
1-6
1.3 Name and Function of Each Part
mA input module (DU300-11/DU300-12)
Cover
Screw
terminal
Cover
Clamp
terminal
Power monitor module (DU400-12/22)
Cover
Wire clip
Clamp terminal
Strain input module (DU500-12/DU500-13/DU500-14)
DU500-14
DU500-12/DU500-13
NDI terminal
Gauge method setup switch
Clamp terminal
Cover
