8-5
IM 04L31A01-01E
Procedures for Disassembly (CX1000)
8
Removing the Drive
1.
Remove the screw as shown in the figure below.
2.
Remove the drive by pulling it outwards.
CAUTION
The ZIP drive has a thin transparent plate that can be sharp. Take care not to
cut your fingers when removing the drive.
CX with all boards and the drive removed.
8.2 Removing the Board Assemblies and the Drive
