A4.4 top view, A4.4, A4-3 – Yokogawa YFGW610 User Manual
Page 16
A4-3
IM 01W02D02-01EN
A4.4
Top view
Ground terminal
Power supply connector
FA0404
Figure A4-4 Top view
There are power supply connectors and a ground terminal on the top of YFGW610.
The spring terminals, which are the main components of the power supply connector to connect
external wiring, are fixed by fastening the two screws of the terminals in the sockets of the hous-
ing.
