REF
#
PN
DESCRIPTION
-WR
QTY
All Other
QTY
PRODUCT MODEL
VSP-WV
VSP-B
VSP-R
VSP-SC
TIRE/AXLE ASSY
2
72460024
1
1
3
11990119
Axle Bolt 3/4-10 x 6" GRADE 5
1
1
4
12990026
NUT, NYLOCK JAM 3/4-10 Z
1
1
PLATFORM/YOKE ASSY
93210001
91210001
92210001
94210001
6
17460005
BUSGIN, RUBBER, PUSH ARM
2
2
7
96460003
FRONT DECK LIFT AXEL BUSHING SPANNER , WSES
2
2
8
13990002
WASHER, FLAT USS Z
3
3
9
11990055
BOLT, FLANGE 1/2-20 X 1-1/2 Z5
2
2
10
12990055
NUT, NYLOCK 1/2-13
1
1
10A
12990018
NUT, NYLOCK JAM 1/2-20
2
2
11
17210000
FOOTPAD, VEKE SUPER PRO, BLACK GRIT
2
2
12
16410013
SPRING
1
1
93210002
WHEEL YOKE WELDMENT, VELKE SUPER PRO, WRIGHT ORANGE
91210002
92210002
94210002
14
11990015
BOLT, FLANGE 1/2-13 X 1-3/4 Z5
1
1
15
12990044
NUT, U 1/4-20 7GA
6
6
16
11990024
TRUSS HD MACH 1/4-20 X 3/4 SS
6
6
17
72460025
SSV WHEEL COVER [RUBBERIZED FENDER]
1
1
ARM ASSY
18
13990023
MACH BUSH, 1-1/4 ID X 1-7/8 OD X 14GA
2
2
19
15990013
LINCH PIN, 7/16 FOR CASTERS
1
1
93220002
ARM WELDMENT, VELKE SUPER PRO, WRIGHT ORANGE
91220002
92220002
94220002
HITCH ASSY
21
96230001
HITCH PIVOT PIN WELDMENT, VELKE SUPER PRO, PLATED
1
1
22
12990020
NUT, NYLOC 3/8-16
2
2
23
VKXLPIN
LINCH PIN X2 AXEL
1
1
24
91230001
HITCH WELDMENT, VELKE SUPER PRO, Black
1
1
25
VADAPTER
ADAPTER PLATE FOR VELKE
0
1
26
11990026
BOLT, HEX 3/8-16 X 1 Z5
2
2
27
VELKIT2-2
HARDWARE KIT FOR VELKE
0
1
*
LUBE WARNING
Literature - Bearing Lube Warning
1
1
Product Literature Bag includes 1 each of:
Literature - VSP Instructions/IPL/Safety
Literature - Four Best Workers
Literature - Registration
Plastic Bag, 9X12X.002
*
BOX, VELKE SUPER PRO
Packaging , Box
1
1
* Shipped with product
PLATFORM WELDMENT ASSEMBLY, VELKE SUPER PRO
,
Wright Orange
PLATFORM WELDMENT ASSEMBLY -Scag Orange [SC]
WHEEL YOKE WELDMENT, VELKE SUPER PRO -Black
WHEEL YOKE WELDMENT, VELKE SUPER PRO -Red
PLATFORM WELDMENT ASSEMBLY -Red
WHEEL YOKE WELDMENT, VELKE SUPER PRO -Scag Orange
ARM WELDMENT, VELKE SUPER PRO -Black
ARM WELDMENT, VELKE SUPER PRO -Red
PRODUCT BAG, VSP
1
1
ARM WELDMENT, VELKE SUPER PRO -Scag Orange [SC]
*
VELKE, SUPER PRO -Black
VELKE, SUPER PRO -Red
VELKE, SUPER PRO -Scag Orange [SC]
VELKE SUPER PRO WHEEL ASSEMBLY
VELKE, SUPER PRO, Wright Orange
[ADAPTER & KIT (REF# 27) NOT INCLUDED]
1
5
13
20
PARTS LIST
1
1
1
1
1
1
1
1
Revised: 1/9/2008
