Versa-Matic 1 Elima-Matic Bolted Metal – Food Processing (E1) - Manual (Page 7)

e1mdlCsmFP-rev0314
www
.
versamatic
.
com Model E1 Metallic Bolted •
4
E1 Metallic Bolted
Dimensions in inches (mm dimensions in brackets)
The dimensions on this drawing are for reference only. A certified drawing can be requested if physical dimensions are needed.
dimensional drawings
1.98 O.D.
DISCHARGE TRI-
CLAMP FLANGE
50.29
1.98 O.D.
SUCTION TRI-
CLAMP FLANGE
50.29
10.93
277.60
.38
9.53
13.63
346.15
10.72
272.39
1.56
39.62
3/8" NPT
AIR INLET
2.00
50.80
14.44
366.79
8.13
206.38
9.27
235.36
1/2" NPT
AIR EXHAUST
4.81
122.22
7.81
198.37
.44
11.18
3.56
90.47
10.15
257.81
1.70
43.18
BOTTOM VIEW
1.98 O.D.
DISCHARGE TRI-
CLAMP FLANGE
50.29
1.98 O.D.
SUCTION TRI-
CLAMP FLANGE
50.29
10.93
277.60
.38
9.53
13.63
346.15
10.72
272.39
1.56
39.62
3/8" NPT
AIR INLET
2.00
50.80
14.44
366.79
8.13
206.38
9.27
235.36
1/2" NPT
AIR EXHAUST
4.81
122.22
7.81
198.37
.44
11.18
3.56
90.47
10.15
257.81
1.70
43.18
BOTTOM VIEW
Model Specific
1: PUMP
SPECS
