Versa-Matic 2 Bolted Plastic Ball Valve Pumps (RE2P) - Manual (Page 16)

re2nmdlAsm-rev0314
www
.
versamatic
.
com
3: EXP
VIEW
13
• Model RE2 Plastic Bolted
Composite Repair Parts list
AIR VALVE ASSEMBLY
Item Description Qty Standard: Aluminum
Air Valve Assembly 1 P126-0036
(Includes items 1-11)
1 Valve Body 1 P126-0003
2 Valve Spool 1 P126-0063
3 Valve Spool Glyd Ring 4 P34-204F
4 End Cap 1 P34-300
5 End Cap Gasket 2 P24-205
6 Adapter, Air Inlet 1 P126-0004
7 Tube, Air Inlet Seal 1 P126-0005
8 Air Inlet O-ring 2 560.024.360
9 Valve Gasket 1 P24-202
10 Valve Cap Screw 11 S1001
11 Valve Cap Screw 2 P24-209
AIR END ASSEMBLY
12 Center Block 1 P126-0001
13 Main Shaft Bushing 1 P24-402
14 Air Chamber, Left 1 P126-0047
15 Air Chamber, Right 1 P126-0048
16 Air Chamber Gasket 2 P126-0008
17 Air Chamber Bolt 8 P24-110
18 Bushing 2 P24-105
19 Pilot Shaft 1 P24-104
20 Pilot Shaft Spacer 5 P24-106
21 Pilot Shaft O-Ring 6 P24-107
22 Stop Nut 2 P24-108
23 Muffler Adapter 1 312.039.335
24 Mounting Bracket Left 1 P126-0012
25 Mounting Bracket Right 1 P126-0013
26 Retainer Plate 2 P126-0010
27 Retainer Foam 2 P126-0011
28 Retainer O-Ring 2 560.203.360
29 Retainer Cap Screw 8 P126-0032
30 AirVantage Unit 1 P126-0043
31 AirVantage Unit Cap Screw 4 170.121.330
32 AirVantage Cable 1 P126-0042
33 AirVantage Sensor 1 P126-0035 (Standard) P126-0059 ( PTFE Diaphragm)
34 AirVantage Unit Face Seal O-ring 1 560.011.360
35 AirVantage Connector Plate 1 P126-0055
36 AirVantage Connector Plate O-ring 1 V110BN
37 Muffler 1 530.041.000
DIAPHRAGM ASSEMBLY
Item Description Qty Dome PTFE 2 Pc.
38 Main Shaft O-Ring 2 P24-403 P24-403
39 Main Shaft 1 P24-103 P24-102
40 Inner Diaphragm Plate 2 P126-0014 P126-0058
41 Outer Diaphragm Plate 2 PV226B / KV226B PV221TO / KV2261TO
42 Diaphragm 2 V227XX V227TF
(Refer to Materials Chart)
43 Bumper Washer 2 P24-501 P24-501
44 Back-Up Diaphragm 2 N/A V227TFB
45 Probe Tip 2 846.001.167 846.001.167
46 O-Ring Probe Tip 2 560.201.360 560.201.360
47 Sensor O-Ring 2 560.033.360 560.033.360
MODEL SPECIFIC
