Versa-Matic 2 Bolted Metallic Ball Valve Pumps (RE2) User Manual
Page 3
re2mdlAsm-rev0314
www
.
versamatic
.
com
1: PUMP
SPECS
2: INST
AL
& OP
3: EXP
VIEW
4: W
ARRANTY
Table of Contents
SECTION 1: PumP SPECIfICaTIONS ................1
• Nomenclature
• Performance
• Materials
• Dimensional Drawings
SECTION 2: INSTallaTION & OPERaTION ......6
• Principle of Pump Operation
• Typical Installation Guide
• Troubleshooting
• AirVantage Troubleshooting
SECTION 3: ExPlOdEd VIEw .........................11
• Composite Drawings
• Parts List
• Material Codes
• AirVantage Servicing
SECTION 4: waRRaNTy & CERTIfICaTES ....30
• Warranty
• CE Declaration of Conformity - Machinery
