Model specific – Versa-Matic 3 Elima-Matic Bolted Aluminum - ATEX (E3) User Manual
Page 13
e3mdlCsmATEXAB-rev0514
Model E3 Bolted Aluminum •
10
www
.
versamatic
.
com
Composite Repair Parts List - Elastomeric and TPE Fitted
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V003.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V005.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13&14)
P34-400DC ASY
13
2
Bearing Sleeve
P34-404
14
2
Main Shaft O-Ring
P34-403
15
2
Air Chamber
196.V008.157
16
2
Air Chamber Gasket
P79-109
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V006.000
22
8
O-ring
560.023.358
23
1
Muffler
530.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
Versa-Rugged
Versa-Dome
24
1
Main Shaft
P34-103
25
2
Diaphragm (See Below Material Chart)
V305xx
V306xx
26
2
Outer Diaphragm Plate
V302BDC
VB307
27
2
Inner Diaphragm Plate
V302CDC
V307B
28
12
Bolt
V302G
N/A
29
12
Washer
V302GA
N/A
30
2
Bumper Washer
P34-501
31
2
Back-Up Washer
V302E
32
4
Valve Seat (See Below Material Chart)
V456xx
33
4
Valve Ball (See Below Material Chart)
V455xx
Wet End Assembly
Item #
Qty.
Description
Part Number
34
2
Water Chamber
V350FB
35
20
Water Chamber Bolt
V387A
36
52
Nut
V387C
37
52
Washer
V387B
38
2
Manifold Tee
V358FB
39
2
Discharge Elbow
V351E-FB
40
2
Suction Elbow
V352E-FB
41
4
O-Ring
V258xx
42
32
Elbow Bolt
V387D
43
1
Discharge Drop in Manifold
518.V002.156
1
Discharge Drop in Manifold (BSP)
518.V002.156 E
44
1
Suction Drop in Manifold
518.V003.156
1
Suction Drop in Manifold (BSP)
518.V003.156 E
Elastomer Material Specifications
Material
Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
"Ball P/N"
Seat P/N
"Manifold Tee
O-ring P/N"
Neoprene
V305N
V306N
V455N
V456N
N/A
Nitrile
V305BN
V306BN
V455BN
V456BN
V258BN
FKM
V305VT
V306VT
V455VT
V456VT
V258VT
EPDM
V305ND
V306ND
V455ND
V456ND
V258ND
PTFE
N/A
N/A
V455TF
V456TF
V258TFS
Santoprene
V305TPEXL
N/A
V455TPEXL
V456TPEXL
V258XL
Hytrel
V305TPEFG
N/A
V455TPEFG
V456TPEFG
N/A
Geolast
V305G
N/A
N/A
N/A
N/A
MODEL SPECIFIC
3: EXP
VIEW
