DELHI TOWERS
DMX Tower Parts
Cast aluminum ball
bearing. Mast bearing
accepts up to 2” (5.08
cm) masts.
Optional hinge-up base.
Threaded rod allows
vertical adjustments.
Fits DMX-03 to DMX-06
sections.
CBS-03
CBS-04
CBS-05
CBS-06
CBS-07
CBS-08
WADE ANTENNA’S ONGOING POLICY OF CONTINUING DEVELOPMENT MAY RESULT IN SPECIFICATION CHANGES TO ITS PRODUCTS
www.wadeantenna.com
BBMB
HUB 3-6
Cast aluminum mast
clamp for up to 2½” (6.35
cm) masts.
Replacement mast clamp
assemblies with sleeve
bearing.
1½” (3.81 cm) 16 ga. x 8’
(2.44 m) mast as supplied
in DMX and DMXB.
Guy station fits DMX-01T
to DMX-03 sections.
Guy station fits DMX-04
to DMX-06 sections.
244A
TMCA
DM
Mast
GS123
GS456
Universal house bracket
included with DMXB
series but designed to
fit all DMX sections. 1”
(2.54cm) x 30” (76.2cm)
arms.
Heavy gauge base plate
fits DMX-02 or DMX-02S
sections
Set of three 4’ (1.22 m)
long, as shown below.
DMXHB
BP2S
Base
Stubs
Fits DMX-03
Fits DMX-04
Fits DMX-05
Fits DMX-06
Fits DMX-07
Fits DMX-08
DMX-01T
DMX-02
DMX-02S
DMX-02T
DMX-03
DMX-03T
DMX-04
DMX-04T
DMX-04S
DMX-05
DMX-05S
DMX-06
DMX-07
DMX-08
10
5
/
16
“ (26.19 cm)
12
7
/
8
” (32.70 cm)
15” (38.10 cm)
12
7
/
8
” (32.70 cm)
15
1
/
8
” (38.42 cm)
15
1
/
8
” (38.42 cm)
17
3
/
8
” (44.13 cm)
17
3
/
8
” (44.13 cm)
19
11
/
16
” (50.01 cm)
19
1
/
2
” (49.53 cm)
22
3
/
16
“ (56.36 cm)
22“ (55.88 cm)
24
1
/
4
” (62.87 cm)
27
1
/
16
“ (68.74 cm)
12
11
/
16
” (32.23 cm)
14
7
/
8
” (37.78 cm)
14
7
/
8
” (37.78 cm)
14
7
/
8
” (37.78 cm)
16
15
/
16
” (43.02 cm)
16
15
/
16
” (43.02 cm)
19
1
/
4
” (48.90 cm)
19
1
/
4
” (48.90 cm)
19
1
/
4
” (48.90 cm)
21
5
/
8
” (54.93 cm)
21
15
/
16
” (55.22 cm)
24
3
/
16
“ (61.44 cm)
26
11
/
16
” (67.79 cm)
29
1
/
4
” (74.30 cm)
A
B
** Climb shields and hardware kits are also available
GS123
GS456
TMCA
244A
BBMB
HUB 3-6
HUB 7-6
CBS-03
CBS-04
CBS-05
CBS-06
CBS-07
CBS-08
4’
(1.22 m)
A
B
B
A
8’
(2.44 m)
OUR NEW DMX TOWERS HAVE BEEN
ENHANCED IN BOTH LEG PROFILE AND TAPER. THIS FACILITATES IN AN EASIER INSTALLATION AND IMPROVED TOWER STRUCTURE.
Width = 1.67 m
BASE STUBS
IN CONCRETE
76mm
CLEARANCE
152 x 152mm
WIRE MESH
NTS
DEPTH =
1.2 m
CONCRETE REQUIRED = 3.34 cu.m.
MADE IN CANADA
