Inter-M PMU-600 User Manual
Page 11
※Warning : For high impedance systems, connect with matching transformer as the following Figure. Be
certain that the total impedance does not equal less than the rated impedance.
SP 5 is output terminal with ATTENUATOR function, and a recommended speaker is lower than
50W(total impedance is upper than 200ohm). Please becareful of connecting the speakers.
Please do not use a 8Ω+8Ω and SP1~SP5 terminal at the same time.
Low Impedance
(100V)
(70V)
PMU-360
8Ω+8Ω
28Ω
14Ω
PMU-480
8Ω+8Ω
21Ω
10Ω
PMU-600
8Ω+8Ω
16Ω
8Ω
MIXING AMPLIFIER
9
PMU-360/480/600
