Names of the parts – IAI America RCLE-GR5L User Manual
Page 15
9
Names of the Parts
WT
BK
Driving Power Supply
Cable bending radius 33mm or more
BR
BL
BK
BR
BL
BK
Cable for Position Sensor
Cable bending radius
7mm or more
Cable for Position Sensor
Position Sensor
Position Sensor
Cable for Position Sensor
With Position Sensor (Option)
Frame
Side yoke
Fingers
Cable
(
+24V)
(0V)
(
+24V)
(0V)
(Detection signal)
(
+24V)
(0V)
(Detection signal)
