Page 29
2. Installation
23
2.3 How to Install
This chapter explains how to install the actuator on your mechanical system.
2.3.1 General Rules on Installation
{
: Possible u : Not possible
Horizontal
installation
Vertical
installation
Sideway
installation
Ceiling mount
installation
{
{
{
{
Installation Orientation
Horizontal
Vertical
Sideway
Ceiling Mount
