4. Verify operation of manual start.
P Press the START button on the Main operator panel and verify that all tools run in the
correct direction until the pre-programmed time elapses, creating both a TIME reject
and a TORQUE reject. The TIME and TORQUE on each Axis unit will light (orange).
(See NOTE3).
P Press the RESET button on the Main operator panel to clear the REJECT light and
LED outputs from the Axis Units.
NOTE3: If any Axis unit fails to indicate a TIME and/or TORQUE reject (and assuming the previous
verifications were completed), then verify that the correct presets have been entered into the
System for that spindle.
5. Verify System operation by external commands.
P Confirm that the equipment operates correctly when PLC inputs and outputs are
activated. Use the PLC to perform all of the functions (START, CAL, etc.) that were
manually activated earlier in this Section.
Chapter 5: Power Up and Initial Checks (Rev. 8/98)
Page 5-4
