Parts list – Welch Vacuum 1400 Duoseal Belt Drive User Manual
Page 17
ITEM
QTY
P/N
A*
B*
DESCRIPTION
1
1
2-00-2704
SCREW PAN HD 10-32 x 1/4” LG.
2
5
2-00-2706
SCREW PAN HD 10-32 x 3/8” LG.
3
3
2-00-6712
SCREW SOCKET HD 10-32 x 3/4” LG.
4
5
2-01-0112
SCREW HEX HD 1/4-20 x 3/4” LG.
5
1
2-01-0120
SCREW SOCKET HD 1/4-20 x 1-1/4” LG.
6
9
2-01-0332
SCREW HEX HD 5/16-18 x 2” LG.
7
2
2-01-6516
SCREW SOCKET HD 3/8-16 x 1” LG.
8
4
2-01-9306
SETSCREW 5/16-18X38”
9
2
2-61-0571
WASHER 3/8” ID
10
2
2-71-0040
2
2
WASHER FLAT #10 BRASS
11
1
41-0383
1
1
GASKET - SILICONE BEAD
12
1
41-0578
1
1
LIP SEAL
13
2
41-0613
2
2
WOODRUFF KEY #404
14
1
41-0624
1
1
WOODRUFF KEY
15
1
41-0643
GASKET, SEAL
16
1
41-0890
1
1
INTAKE SCREEN
17
1
41-1039
VENTED EXHAUST PLUG
18
2
41-1040
ROTOR
19
1
41-1042
4
INNER RING
20
1
41-1045
FRONT PLATE
21
1
41-1048
INTAKE CHAMBER ASSEMBLY
22
1
41-1052
1
1
GASKET
23
2
41-1056
WASHER
24
4
41-1059
VANE
25
1
41-1060
SHAFT
PARTS LIST
A*: Major Repair Kit Catalog # 1400K-04
B*: Minor Repair Kit Catalog # 1400K-03
+ Item 41 exploded view shown on page 18
1401E is a Mechanical Seal Kit which includes a mechanical seal, gasket, and 3 screws.
ITEM
QTY
P/N
A*
B*
DESCRIPTION
26
2
41-1063
2
2
SPRING HOLDER FOR VANES
27
1
41-1069
1
1
BAFFLE STUD
28
6
41-1138
WASHER 7/16” O/D COPER
29
1
41-1150
1
1
RETAINING RING
30
1
41-1239
EXHAUST VLAVE
31
1
41-1285
STEEL WASHER FOR SHAFT COLLAR
32
4
41-1304
VANE SPRING
33
1
41-1736
GAS BALLAST VALVE
34
1
41-2191
PULLEY WITH SET SCREW
35
8
41-2363
WASHER 5/16 ID X1/2 OD
36
1
41-2757
LOCK NUT
37
1
41-3696
OUTER LIP SEAL ASSEMBLY
38
1
61-6076A
EXHAUST PLUG SMALL
39
1
61-8347B
VALVE COVER
40
1
61-8456A
WASHER 5/16”, COPPER
+41
1
61-8540C
OIL CASE ASSEMBLY
42
1
61-8665
1
1
O-RING FLUOROELASTOMER
86mmX2.5mm
43
1
61-8673
SHAFT END CAP
44
1
61-8675
INTAKE RING
45
1
61-8679
1
1
CENTER PLATE
46
1
61-8702
1
1
BACK END PLATE
47
1
61-9378
O-RING #152, FLUOROELASTOMER
48
1
66-0183
O-RING #120, FLUOROELASTOMER
N/S
1-99-5282
1
1
SEALANT, 6cc
N/S
1401E
1
1
MECHANICAL SEAL KIT
17
