Zwischenboden: Ein geeignetes Zubehörteil kann über unseren

Kundendienst bezogen werden. Die Artikelnummer für dieses

Zubehörteil lautet 448964.
Arbeitsplatte: Muss über eine Dicke von mindestens 20 mm ver-

fügen.
Der Abstand zwischen dem oberen Bereich der Arbeitsplatte

und dem oberen Bereich des Schubfachs muss 65 mm betra-

gen.
Montage über dem Backofen, Abbildung 2b

Arbeitsplatte: Muss über folgende Mindestdicke verfügen:

20 mm bei Einbau über einem Kompaktbackofen.

30 mm bei Einbau über einem normalen Backofen.

Bei Einbau über einem Kompaktbackofen muss sich ein

Abstand von 60 mm zwischen dem oberen Teil des Backofens

und dem oberen Teil der Arbeitsplatte befinden.
Einbau über einem Geschirrspüler, Abbildung 2c

Es muss ein Zubehörteil dazwischen eingebaut werden. Zube-

hörteile erhalten Sie bei unserem Kundendienst. Die Artikelnum-

mer für dieses Zubehörteil lautet 448964.
Arbeitsplatte: Muss über eine Dicke von mindestens von 20 mm

und höchstens 40 mm verfügen.
Es muss folgender Abstand zwischen dem oberen Bereich der

Arbeitsplatte und dem oberen Bereich des Geschirrspülers ein-

gehalten werden:

60 mm bei Einbau über einem Kompakt-Geschirrspüler.

65 mm bei Einbau über einem normalen Geschirrspüler.

Gebläse, Abbildung 3

Für die Lüftung des Kochfelds ist Folgendes notwendig:

Eine Öffnung im oberen Bereich der Rückwand des Möbels

(Abb. 3a).

Ein Abstand zwischen der Rückwand des Möbels und der

Küchenwand (Abb. 3b).

Einbau des Geräts, Abb. 4/5

1. Die mitgelieferten Verankerungen einbauen

(Abb. 4).

Hinweis: Keine elektrischen Schraubendreher verwenden.

2. Das Gerät ans Stromnetz anschließen und auf ordnungsge-

mäßen Betrieb überprüfen.
– Hinweise zur elektrischen Spannung siehe Typenschild.
– Nur nach dem Anschlussplan anschließen (Abb. 5).

1. Braun
2. Blau
3. Gelb und grün

Ausbau des Geräts

Das Gerät von der Stromzufuhr trennen.
Die Halterungen entfernen.
Entnehmen Sie das Kochfeld, indem Sie von unten dagegen

drücken.
Achtung!

Schäden am Gerät! Versuchen Sie nicht, das Gerät durch

Hebeln von oben zu entnehmen.

en

Ú

Ins tallation ins tructions

Important notes

Safety: Safety in use is only guaranteed if the technical

installation of the hob has been carried out correctly and in

accordance with the assembly instructions. The installation

technician shall be liable for any damage caused as a result of

unsuitable installation.
Electric connection: Only by an authorised specialist

technician. The guidelines set out by the local electricity provider

must be observed.
Type of connection: The appliance falls under protection class I

and can only be used in combination with a grounding

conductor connection.
The manufacturer accepts no responsibility for any malfunction

or damage caused by incorrect electrical installations.
Installation: The appliance must be connected to a fixed

installation and the means of disconnecting it from the fixed

installation must be installed according to the installation

instructions.

Built-in assembly under worktop: The induction hobs may only

be installed over a drawer, ovens with forced ventilation from the

same brand and dishwashers from the same brand.

Refrigerators, unventilated ovens and washing machines may

not be installed beneath the hob.
Power cable: Do not tie the power cable or pass it along sharp

edges. If there is an oven installed below, pass the cable along

the rear corners of the oven to the connection box. It must be

positioned so that it does not touch any of the hot parts of the

hob or the oven.
Hob: flat, horizontal, stable. Follow the hob manufacturer's

instructions.
Warranty: an unsuitable installation, connection or assembly will

invalidate the product warranty.
Note: Any change to the appliance's interior, including changing

the power cable, must only be performed by specially trained

members of the Technical Assistance Service.

Preparation of assembly units, figures 1/2/3

Built-in kitchen units: Minimum temperature resistance of

90°C.
Gap: Remove any shavings after performing cutting work.
Cut surfaces: Seal with heat resistant material.
Assembly over drawer, figure 2a

Metal objects stored inside the drawer could become very hot

due to the air recirculating from the hob ventilation system. If

this occurs, an intermediate support is recommended.
Intermediate support: An appropriate accessory can be

obtained from our Technical Assistance Service. The reference

code for this accessory is 448964.
Worktop: Must have a minimum thickness of 20 mm.
The distance between the top of the working surface and the top

of the drawer must be 65 mm.
Assembly over oven, figure 2b

Worktop: Must have a minimum thickness of:

20 mm if installed over a compact oven.

30 mm if installed over a full-size oven.

If the hob is installed over a compact oven, there must be a

distance of 60 mm between the top of the oven and the top of

the working surface.
Assembly over dishwasher, figure 2c

An intermediate accessory must be installed. The accessory

may be ordered from our Technical Assistance Service. The

reference code for this accessory is 448964.
Worktop: Must have a minimum thickness of 20 mm and

maximum thickness of 40 mm.
The space between the top of the working surface and the top

of the dishwasher must be:

60 mm if installed over a compact dishwasher.

65 mm if installed over a full-size dishwasher.

Ventilation, figure 3

Ventilating the hob requires:

an opening on the upper part of the kitchen unit's rear wall

(figure 3a).

a separation between the rear part of the kitchen unit and

kitchen wall (figure 3b).

Installing the appliance, figures 4/5

1. Secure the anchor bolts supplied

(figure 4).

Note: Do not use electric screwdrivers.

2. Connect the appliance to the mains to check its working.

– Voltage, see specifications plate.
– Connect according to the connection drawing only

(figure 5).

1. Brown
2. Blue
3. Yellow and green

Uninstalling the appliance

Disconnect the appliance from the mains.
Remove the anchoring devices.
Push the hob upwards from below to remove it.
Caution!

Damage to the appliance! Do not try to remove the appliance by

prying it out from above.
