Upgrading systems
Figure 8 shows the different 8510 systems and their components. This
figure is an excellent guide when upgrading systems.
Figure 8. 8510 family of system solutions
To upgrade from one system to another, simply order the pieces that are needed
in the new system that are currently not in the existing system, an example
is shown in Figure 9. Complete waveguide S-parameter systems require two
test set modules for each band.
1 Necessary accessories such as calibration kits,
verification kits, test port cables or adapters 2 must be ordered. See pages 17
through 19 for more information.
Pulsed-RF
or CW
systems
Single-sweep
high
performance
systems
8510C
85110L
83620B #H80
83620B #H80
85108L
0.045 to 2 GHz
8510C
85110A
83622B
83623L
85108A*
2 to 20 GHz
8510C
85110A (50 GHz)
83650B
83621B
85108A (50 GHz)
2 to 50 GHz
8510E
0.045 to 20 GHz
8510C
8514B
83621B
8510SX
0.045 to 26.5 GHz
8510C
8515A
83631B
85107B
0.045 to 50 GHz
8510C
8517B
83651B
8510XF
0.045 to 110 GHz
8510C
MM-wave subsystem
83651B
83621B
* 85108A also available in frequency range of 45 MHz to 20 GHz
Waveguide
systems
Q-band
8510C
85105A
83621B
83621B
85106D
33 to 110 GHz
V-band
W-band
+
OR
OR
OR
Q-band
8510C
85105A #050
8517B
83621B
83651B
85106D #001
0.045 to 110 GHz
U-band
V-band
W-band
+
OR
OR
OR
U-band
1. The following test set modules are available. Two test set modules must be ordered for complete waveguide
S-parameter test set operation for each waveguide band:
• Q85104A test set module (33 GHz to 50 GHz)
• U85104A test set module (40 GHz to 60 GHz)
• V85104A test set module (50 GHz to 75 GHz)
• W85104A test set module (75 GHz to 110 GHz)
2. Please refer to the RF & Microwave Test Accessories Catalog (literature number 5964-9527E) on detailed
information on available adapters.
