Atlantis Land 800NV User Manual

Netcamera 800nv, Package contents system requirements connectors, Quick start guide

background image

Package contents

System requirements

Connectors

Audio output:

Audio input:

Video output: analog video output

Power:

Network: ethernet 802.3 af port, to provide power and ethernet signal to the

NetCamera.

connect here an external speaker.

connect here a microphone.

.

use this connector to use an external power supply (12V,1 A not included).

Before proceed with the product usage please check the package contents:
-IP Camera
-PoE Injector with power cord
-Mounting screws
-Quick Start Guide
-CD-ROM

Configuration

Turn on your PC and put the provided CD-Rom in your CD-Rom reader. A welcome
page will appear. Select the purchased NetCamera and click on “Intelligent IP
Installer” link, then follow the next steps.

1 .Click ”

” to proceed with the installation procedure

Yes

- 1 -

-2 -

- 4 -

- 3 -

2. Select desired language an click ”Next”

3. Click

to go to the next step

"Next”

4 .Click

to go to the next step

"Next”

5 .Click

to go to the next step

"Next”

6 .Click

to go to the next step

"Next”

7 .Click ”

” then

to complete

the installation procedure.

Install

“Finish”

Before proceed with product installation, please make sure your system is in
compliance with the following requirements:

-Windows 98, ME, 2000, 2003, XP or Vista
-Internet Explorer 6.0 or later

QUICK START GUIDE

A02-OIPCAM1_GE01

www.atlantis-land.com

NetCamera 800NV

A02-OIPCAM1

Green: Audio output
Red: Microphone input

Video output

Power

Network (PoE)
