KT&C KPC-N635NH10 User Manual

Page 13

3rd axis

Loosen lock ring and set screw to rotate camera 360°

Sunshield
To remove or install the sunshield, use flat blade screw driver to loosen the screw at sunshield.

Secure with this screw

Note:

When properly installed, the rear of the sunshield is even with the rear of the camera body; improperly extending

the sunshield to ‘shade’ the lens can compromise image quality.
