6. INSTALLATION

10

Cover Screws(3ea):
are “captive and will
normally be retained in
cover. They are shown
here for illustration
purposes.

Screws(3ea)

Plastic Anchors
(3ea)

Template

Lens Zoom Knob

Lens Focus Knob

When using the camera

without LED take off the rubber.

N O T E
