169mm (6.6”)
150mm (5.9”)
44mm (1.7”)
Physical Dimension
Modem
Transmitter
Receiver
General
Models BSR100D TM
VHF
BSRU100D TM UHF
Band
Frequency Stability
Sensitivity
Selectivity
Inter-modulation
Spurious and Image
Rejection
Data Rate
Modulation
136-174 MHz
5ppm
-117dBm @ 12dB SINAD
65dB for 12.5 KHz
70dB
4800, 9600, 19,200 (B.W = 25 Khz)
DRCMSK
RF Output Power
Frequency Stability 10 Watts (Nominal)
Frequency Range
Channel Bandwidth
12.5 KHz
PC programming Programming
FCC Type Acceptance H78KPBSR100D
10-15 VDC (12.5 VDC nominal) Operating Voltage
Current Consumption
150mA STBY; 3A TX
Diagnostics
Overload trouble, drive fault, timeout, PLL lock,
dead battery, power trouble, RSSI
410-510 MHz
H78KPBSRU100D
160mA STBY; 3A TX
BSR100D BSRU100D
70dB
Spurious Emission -65dB
2.5ppm @ -30oC to 60oC (22oF to 140oF) +-
Size
Weight
169x150x44 mm (6.6”x5.9”x1.7
0.65 kg (1.44 Lbs)
Bit Error Rate
Signal Level
Better Than 1 x 10-5 @ 1.0m V
Data Format Asynchronous, serial, transparent
EIA RS-232C
Word Length
Parity 7 or 8 bit words, 1 or 2 stop bits
Even, odd, or none
Handshake
RTS/CTS Delay
RTS-CTS
Diagnostics Power, TX RX, internal temp
Min 20 msec
Operating Temperature
Storage Temperature
-30 o C to 60 o C (-54 o F to 108 o F)
-40 o C to 80 o C (-72 o F to 144 o F)
+-
Specifications
Frequency Hopping 1 out of 8 , (on - the - fly)
Typical Telemetry Application
“Pump Control Station”
