Fluid Components International ST98 Manual Drawings User Manual
Page 7
Doc. No. 06EN003291 Rev. A
A - 7
Model ST98 Flow Meter
APPENDIX A - DRAWINGS
FLUID COMPONENTS INTL
0.00375 OHMS/OHMS/°C 1000 OHMS PLATINUM
TEMPERATURE VERSUS RESISTANCE
(Sheet 2 of 3)
T(°F)
OHMS
T(°F)
OHMS
T(°F)
OHMS
T(°F)
OHMS
132
1209.762
175
1298.661
218
1386.609
261
1473.427
133
1211.839
176
1300.717
219
1388.641
262
1475.431
134
1213.916
177
1302.773
220
1390.673
263
1477.434
135
1215.992
178
1304.829
221
1392.705
264
1479.436
136
1218.068
179
1306.884
222
1394.736
265
1481.438
137
1220.143
180
1308.939
223
1396.766
266
1483.439
138
1222.218
181
1310.993
224
1398.795
267
1485.439
139
1224.293
182
1313.047
225
1400.824
268
1487.439
140
1226.367
183
1315.100
226
1402.853
269
1489.437
141
1228.440
184
1317.152
227
1404.880
270
1491.435
142
1230.513
185
1319.204
228
1406.907
271
1493.432
143
1232.586
186
1321.256
229
1408.934
272
1495.429
144
1234.658
187
1323.307
230
1410.959
273
1497.424
145
1236.730
188
1325.357
231
1412.985
274
1499.419
146
1238.801
189
1327.407
232
1415.009
275
1501.413
147
1240.872
190
1329.456
233
1417.033
276
1503.407
148
1242.942
191
1331.505
234
1419.056
277
1505.399
149
1245.012
192
1333.553
235
1421.079
278
1507.391
150
1247.082
193
1335.601
236
1423.101
279
1509.382
151
1249.151
194
1337.648
237
1425.122
280
1511.372
152
1251.219
195
1339.695
238
1427.142
281
1513.361
153
1253.287
196
1341.741
239
1429.162
282
1515.350
154
1255.355
197
1343.786
240
1431.182
283
1517.338
155
1257.422
198
1345.831
241
1433.200
284
1519.325
156
1259.488
199
1347.875
242
1435.218
285
1521.311
157
1261.554
200
1349.919
243
1437.235
286
1523.296
158
1263.620
201
1351.962
244
1439.252
287
1525.281
159
1265.685
202
1354.005
245
1441.268
288
1527.264
160
1267.750
203
1356.047
246
1443.283
289
1529.247
161
1269.814
204
1358.089
247
1445.298
290
1531.229
162
1271.878
205
1360.130
248
1447.311
291
1533.210
163
1273.941
206
1362.170
249
1449.324
292
1535.191
164
1276.003
207
1364.210
250
1451.337
293
1537.170
165
1278.066
208
1366.249
251
1453.349
294
1539.149
166
1280.127
209
1368.288
252
1455.360
295
1541.127
167
1282.189
210
1370.326
253
1457.370
296
1543.104
168
1284.249
211
1372.363
254
1459.380
297
1545.080
169
1286.310
212
1374.400
255
1461.389
298
1547.056
170
1288.369
213
1376.436
256
1463.397
299
1549.030
171
1290.429
214
1378.472
257
1465.404
300
1551.004
172
1292.487
215
1380.507
258
1467.411
301
1552.977
173
1294.546
216
1382.541
259
1469.417
302
1554.948
174
1296.603
217
1384.575
260
1471.422
303
1556.919
