11
WS­4/WS­10 & EWS­4/EWS­10 SPECIFICATIONS
<'(()6,',-%&)>?@A)E);2"#F"&/7)<'(()6,',-%&)>?@A)6!;G*C*GDH*B06
Frequency Response (electronics): +0,-1dB, 100Hz to 20kHz A/D Converters: 24-bit (48kHz sampling)
Effective Input Headroom: 30dB Connection: RJ45 with shielded Ethernet/PoE
cable (CAT5, CAT5e, CAT6 or CAT7)
Gain: Adjustable in 1dB steps
over a 30dB range
Power:
Aux: 802.3af (PoE) Class 2
24V DC 6W
System Headroom: 18dB Overall Dimensions
(excl. microphone):
Height:
Width:
Depth: 5.3 inches (135mm)
11.9 inches (302mm)
1.9 inches (48mm)
Maximum Input: 125dB SPL Mic Cord Length (extended): 4 ft (1200mm)
THD + N (100Hz to 8kHz): <0.05% Weight: Approx. 2.6 lbs. (1.2kg)
Mic Type: Noise canceling dynamic
microphone with dual transducer
(monitored)
Ambient Operating
Temperature Range: 32-113 degrees F (0-45 degrees C)
Mic Pattern:
Mic Frequency Response (1cm):
Noise cancelling cardioid
100Hz-10kHz
Compliance: FCC part 15, class B
CE marked
RoHS Directive
UL 60065 Listed, E215636
C-UL Listed, E215636
C-Tick, N24138 (Australia)
<'(()6,',-%&)>?@A)E);2"#F"&/7)<'(()6,',-%&)>?@A)I(%/J)8-'F#'2)
Test Gen
Gain
CobraNet
audio and
control
A/D PoE
CobraNet
Processor
Keypad
LCD
ID Switches
Aux Port
Microphone
HostProcessor
