Service information – Ampeg PF-350 User Manual
Page 17

PF-350 / PF-500 / PF-800 Bass Guitar Amplifier
17
Service Information
If you are having a problem with your PF-500 / PF-800, you can go to our website
(www.ampeg.com) and click on Support for service information, or call Technical Support
at 1-800-898-3211 Monday-Friday during normal business hours, Pacific Time, to receive
assistance. If you are outside of the U.S., contact your local distributor for technical support
and service.
PF-500 / PF-800 TECHNICAL SPECIFICATIONS
Output Power Rating
300 watts rms @ 8 ohms, 3% THD [PF-500]
500 watts rms @ 4 ohms, 3% THD [PF-500]
400 watts rms @ 8 ohms, 3% THD [PF-800]
800 watts rms @ 4 ohms, 3% THD [PF-800]
Signal to Noise Ratio
72 dB (20 Hz–20 kHz, unweighted) [PF-500]
74 dB (20 Hz–20 kHz, unweighted) [PF-800]
Maximum Gain
69 dB, tone controls centered [PF-500]
71 dB, tone controls centered [PF-800]
Tone Controls
Bass: +12/–12 dB @ 40 Hz
Midrange: +10/–20 dB @ 220 Hz, 450 Hz,
800 Hz, 1.6 kHz or 3 kHz
Treble: +15/–20 dB @ 4 kHz
Power Requirements
~100–120 VAC, 50–60 Hz, 125W [PF-500]
~200–240 VAC, 50–60 Hz, 125W [PF-500]
~100–120 VAC, 50–60 Hz, 200W [PF-800]
~200–240 VAC, 50–60 Hz, 200W [PF-800]
Size (H x W x D)
3.1 in/80 mm x 14.0 in/355 mm
x 10.8 in/272 mm [PF-500]
3.1 in/80 mm x 15.0 in/381 mm
x 10.8 in/272 mm [PF-800]
Weight
11.0 lb/5.0 kg (approximately) [PF-500]
11.8 lb/5.4 kg (approximately) [PF-800]
The PF-500/PF-800 is covered with sheet metal, so be sure to clean with a dry lint-free cloth. Never
spray cleaning agents on the PF-500/PF-800. Avoid abrasive cleansers which would damage the finish.
Ampeg continually develops new products and improves upon existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
“Ampeg” is a registered trademark of LOUD Technologies Inc. All other brand names mentioned are trademarks
or registered trademarks of their respective holders and are hereby acknowledged.
