Yamaha, Connectors – MoTeC PWC Plug-In ECU User Manual
Page 45
38
Appendices
Yamaha
Connectors
M400 Marine ECU Connector
Looking into the connector on the ECU
Yamaha Factory Connector
Looking into the connector on the ECU
Note: Do not refer to the pin numbers moulded into the back of the Yamaha
connectors as some of the numbers are repeated on each connector.
MoTeC
Do not refer to the pin numbers moulded into the back of the Yamaha
connectors as some of the numbers are repeated on each connector.
