10 kv voltage power supply characteristics

Model 2290-10
Keithley Instruments, Inc.
10 kV Voltage Power Supply Characteristics
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
Specifications are subject to change without notice.
SPEC-2290-10 Rev. A / December 2013
Page 1 of 3
CONDITIONS
This document contains specifications and supplemental information for the Model 2290-10 High Voltage
Power Supply. Specifications are the standards against which the Model 2290-10 is tested. Upon leaving
the factory, the Model 2290-10 meets these specifications. Characteristics, supplemental characteristics,
and typical values are not warranted, apply at 23 °C ± 5 °C, < 70% relative humidity, and are provided
solely as useful information.
CHARACTERISTICS
Voltage range:
Output voltage
Maximum output current
+100 to +10,000 V DC
1.000 mA DC
Voltage set accuracy: ±0.06% of full scale
Voltage display accuracy: voltage set accuracy ±1 V, typical (±2 V, maximum)
Voltage resolution: 1 V (set and display)
Voltage limit range: 0 to 100% full scale
Voltage regulation
:
Line: 0.001% for ±10% line voltage change
Load: 0.04% for 100% load change, typical
Output ripple (300Hz – 300 kHz):
0.01% of full scale, V RMS
Rise time (from high voltage turn on to final value under full load)
3,
:
<6 seconds to within 1 V of the final value
Discharge time (to 0 V under fulll load)
3, 4
:
<1 second to under 10 V
Discharge time (no load)
3
:
<6 seconds (to <1% of full scale voltage with no load, typical)
Output Stored Charge: <20 µC maximum
1
The output voltage can be programmed to voltages below 100 V, but accuracy below 100 V is not specified.
2
Regulation specifications apply for greater than 100 V
3
Current limit set to 105% of full scale.
4
Under resistive load.
