24
Article number TVCC20030 TVCC20530 TVCC20041 TVCC20541
Standard PAL
Resolution 520 TVL 520 TVL
Image sensor 1/3“ Sony CCD 1/3“ WD CCD
Picture elements (total) 795 Pixel (H) x 596 Pixel (V) 795 Pixel (H) x 596 Pixel (V)
Picture elements (effective) 752 Pixel (H) x 582 Pixel (V) 752 Pixel (H) x 582 Pixel (V)
Signal-to-noise ratio 48 dB 48 dB
Minimum light sensitivity
(day)
0.2 Lux @ F1.0, 30 IRE 0.1 Lux @ F1.0, 30 IRE
Minimum light sensitivity
(night) 0.01 Lux @ F1.0, 30 IRE (S/W
Modus)
-
Automatic day/night switch Removable infrared filter (ICR),
Color / B/W
Color / B/W
Day/night switch delay 10 sec. -
Lens CS/C-Mount
Synchronization Internal
Automatic Gain Control
(AGC)
Automatic / Off
Shutter AES / AI
Backlight compensation
(BLC)
Automatic, Off -
White balance Automatic White Balance (AWB)
Gamma 0.45
WDR - 46 dB
Iris Level Setup Yes
Mirroring Off / Horizontal
Setup elements 4 DIP, 2 Potentiometer 4 DIP, 1 Potentiometer
Protection class IP 34
Video signal Composite; 1.0V p-p, 75 Ohm
Operating temperature -10°C ~ +50°C
Humidity 0~85% not condensing
Nominal supply voltage 12 VDC 110-240 VAC 12 VDC 110-240 VAC
Power consumption 2.3 W 2.5 W
Dimensions (WxHxD) 55,09 x 40,02 x 98,7 mm
Weight 160 g 290 g 160 g 290 g
4
0.02mm
87.21mm
98.7mm
55.09mm
