6” lgfi round lens – Gotham 6 LGFI Round Lens SpecSheet User Manual
Page 2
© 2010-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 09/03/13. Specifications subject to change without notice.
PAGE 2 OF 3
LGFI-R-6
DIM
EN
SIO
N
AL D
AT
A
6” LGFI
Round Lens
Wet Location, Horizontal DTT or TRT Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
7-1/2
(19.1)
15-9/16
(39.6)
Aperture:
6-1/4 (15.9)
Ceiling Opening: 6-5/8 (16.8)
Overlap Trim:
7-1/2 (19.1)
6-1/4
(15.8)
