3: Controls and Indicators

000-20000-300-02- 201110

Other Controls

Acquisition Controls

Much like controls on a VCR, the Acquisition Controls allow you to pause and resume continuous spectra
acquisition, and perform a single acquisition.

Control

Action

Pause selected acquisition

Perform single acquisition

Resume selected acquisition

Peak Finding

This control (located in the bottom, right corner of the graph) allows you to create a threshold on your
spectral graph to isolate peaks.

Note

If this control does not display on your graph, click in the graph to make it appear.

►

Procedure

1. Click

. A threshold line appears on the graph, along with more Peak Finding controls. The

threshold is set high and in most cases, should be adjusted.
