10
PowerWalker VFI 10000TCP 3/1 REAR VIEW
Fig. 3-1 the rear view of the tower 3-phase series UPS
3.2 Product Specification and Performance
1) General Specification
Model
PowerWalker VFI
10000TP 3/1
PowerWalker VFI
20000TP 3/1
PowerWalker VFI
10000TCP 3/1
Power Rating 10KVA/9KW 20KVA/18KW 10KVA/9KW
Frequency (Hz) 50/60
Input
Voltage (110-276)VAC (Depends on Load Level)
Current L1/L2/L3：23A MAX L1/L2/L3：46A MAX L1/L2/L3：23A MAX
Battery Voltage 288VDC 240VDC
Parallel Port
(Optional)
Intelligent Slot
EPO
、 、
RS232 USB
Fan
AS400
Input Breaker
Terminal Blocks
Cover
External Battery
IEC Connector
Maintenance and Output
Switch Cover
