background image

AMU1206, NEMA Type 4X, Fiberglass Reinforced Enclosure

Compression molded fiberglass reinforced polyester construction with flush, solid/opaque cover

• Allied Moulded Ultraguard

TM

fiberglass reinforced polyester material formulation

- UV stabilized for outdoor use

• Light gray color (RAL 7035)

• Clear, polycarbonate instrumentation cover

• 304 stainless steel captive cover screws, lockable latches, and hinge pin

• Partially molded hinge and molded latch keeper

• Gasket made of closed cell neoprene cord encased in a continuous tongue and groove channel

• Polycarbonate flanges (mounted) and mounting feet (bagged) with four 304 stainless steel screws

• 10-32 threaded brass inserts are installed for back panel mounting

C O N S T R U C T I O N

C O N S T R U C T I O N

A P P L I C A T I O N

A P P L I C A T I O N

S T A N D A R D S

S T A N D A R D S

Construction meets NEMA/EEMAC Type 4, 4X, 12 Specifications

• UL

®

508 and UL

®

50 listed, Type 1, 2, 3, 3R, 4, 4X, 12, 13

• CSA certified file LR 89590-1

• Enclosure flammability rating per UL 508

• Joint Industrial Council (JIC) enclosure sizing

• Compliant with RoHS directive - restriction of hazardous substances

12” x 10” x 6”

12” x 10” x 6”

Designed to insulate and protect controls and components in both indoor and outdoor applications

often found in oil refineries, waste water treatment equipment, and chemical plants

• Especially well suited for high temperature or corrosive environments

• Protects from dirt, dust, oil and water

• For use with industrial control equipment in ordinary locations

• Clear/polycarbonate, instrumentation cover used in applications where critical electronic equipment

must be visible and protected from the elements

Screw Cover

Hinged Screw Cover

Hinged Snap Latch

Hinged Twist Latch

Solid/Opaque

AMU1206F

AMU1206HF

AMU1206LF

AMU1206TF

Clear Cover

AMU1206CCF

AMU1206CCHF

AMU1206CCLF

AMU1206CCTF

View Window

AMU1206WF

AMU1206HWF

AMU1206LWF

AMU1206TWF

Screw Cover

Hinged Screw Cover

Hinged Snap Latch

Hinged Twist Latch

Solid/Opaque

AMU1206

AMU1206H

AMU1206L

AMU1206T

Clear Cover

AMU1206CC

AMU1206CCH

AMU1206CCL

AMU1206CCT

View Window

AMU1206W

AMU1206HW

AMU1206LW

AMU1206TW

Flange mount enclosures (flanges installed)

Foot mount enclosures (four feet bagged and shipped inside enclosure)

Ordering Part Numbers
