Hardware
CPU 32-bit
MCU
UART Interface
COM 1
2-wire RS-485
4-wire RS-422
COM 1 Connector
10-Pin Removable Terminal Block x 1
Protocol
Modbus RTU master
Ethernet Interface
Ethernet
10/100 Base-TX, 8-pin RJ-45 x 1, (Auto-negotiating, Auto-MDI/MDIX, LED
indicator)
PoE (IEEE 802.3af, Class 1)
Protocol EtherNet/IP
adapter
Power
Power supply
PoE: IEEE 802.3af, Class 1
DC jack: +12 ~ 48 V
DC
Power Consumption
0.05 A @ 24 V
DC
Mechanism
Dimensions
52mm x 95mm x 27mm (W x L x H)
Mounting DIN-Rail
Flammability
Fire Retardant Materials (UL94-V0 Level)
Environment
Operating Temperature
-25 ~ 75 ℃
Storage Temperature
-30 ~ 80 ℃
Humidity
10 ~ 90% RH, non-condensing
GW-7472 CR
EtherNet/IP to Modbus RTU gateway with PoE and one RS-422/485 (RoHS)
Application
Ordering Information
