DS2186
041295 10/11
DS2186 TRANSMIT LINE INTERFACE 20–PIN DIP
A
B
C
E
F
G
H
J
K
D
1
DIM MIN MAX
20-PIN PKG
A IN.
MM
B IN.
MM
C IN.
MM
D IN.
MM
E IN.
MM
F IN.
MM
G IN.
MM
H IN.
MM
J IN.
MM
K IN.
MM
1.020
25.91 1.040
26.42
0.240
6.10 0.260
6.60
0.120
3.05 0.140
3.56
0.300
7.62 0.325
8.26
0.015
0.38 0.040
1.02
0.120
3.04 0.140
3.56
0.090
2.23 0.110
2.79
0.320
8.13 0.370
9.40
0.008
0.20 0.012
0.30
0.015
0.38 0.021
0.53
