17
ATA5811/ATA5812 [Preliminary]
4689B–RKE–04/04
Figure 14. Unmodulated TX Spectrum f
FSK_L
Figure 15. FSK-modulated TX Spectrum (20 kBaud/
±
16.17 kHz/Manchester Code)
Sweep 27.5 ms (401 pts)
Ref 10 dBm
Samp
Log
10
dB/
VAvg
5 0
W1 S2
S3 FC
Atten 20 dB
Center 433.92 MHz
Res BW 10 kHz
Span 1 MHz
VBW 10 kHz
Ref 10 dBm Atten 20 dB
Samp
Log
10
dB/
VAvg
5 0
W1 S2
S3 FC
Center 433.92 MHz
Res BW 10 kHz VBW 10 kHz
Span 1 MHz
Sweep 27.5 ms (401 pts)
