DS2153Q
022697 35/48
TRANSMIT SIDE TIMING Figure 13–5
15 16 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 FRAME# 16 1 2 3 4 5 6 14
TSYNC 1
TSYNC 2
TCLK 3
TLINK 3
NOTES:
1. TSYNC in the frame mode (TCR1.1=0).
2. TSYNC in the multiframe mode (TCR1.1=1).
3. TLINK is programmed to source only the Sa4 bit.
4. This diagram assumbes both the CAS MF and the CRC4 begin with the align frame.
