DS26502 T1/E1/J1/64KCC BITS Element

122 of 125

Figure 20-10. Receive Timing, T1, E1, 64KCC Mode

tD1

t D2

RSER

RS_8K

1

RCLK

E1 = MSB of Channel 1
T1 = F-Bit

t D2

RS_8K

2

t D2

400HZ

3

NOTES:
1) RS_8K output in T1 or E1 mode.

2) RS_8K output in 64KCC mode.
3) 400Hz output active only in 64KCC mode, high impedance in all other modes.
