Dual, 2-Wire Hall-Effect Sensor Interface with
Analog and Digital Outputs
MAX9621
4
Timing Diagrams
Figure 2. Hall Input Pulse Rejection
Figure 1. Timing Diagram
t
DEL
t
DEL
IN_
DOUT_
P
R
14mA
7mA
0mA
5V
0V
P
R
IN1
DOUT1
7mA
14mA
APPROXIMATELY 100mA
0mA
0V
5V
HALL SENSOR OPEN
HALL SENSOR
OPEN
SHORT CIRCUIT
APPROXIMATELY 100mA
AOUT1
0.35mA
0mA
5mA/µs
5mA/µs
t
DEL
t
DEL
APPROXIMATELY 1.4mA
RESTART
0.7mA
