Miniature Size
Surface Mount Tantalum Capacitors
MCT
27
FEATURES
z
0402 footprint - Nemco case size P
z
0603 footprint - Nemco case size R
z
Lead-free
z
RoHS compliant
z
Capacitance range: 0.47
μf to 22 μf
z
Voltage range: 2 to 16 WVDC
z
Operating temperature range -55°C to +125°C, 2/3 x Vr (linear derating) above +85°C
z
Meets or exceeds EIA 535 BAAC and IECQ standards (QC300801/US0001, IS - 28)
z
Surge tested for maximum robustness
z
Laser marking polarity stripe
z
Encapsulant material satisfies the UL 94 VO flammability classification
z
MSL (
moisture sensitivity level) per IPC/Jedec J-STD-020B is level 1
Miniature
Surface Mount Tantalum Capacitors
nemco
Lead Free
Pb
RoHS
compliant
0603
footprint
case size
R
0402
footprint
case size
P
