AM900SET – CENTRAL DOOR LOCKING SYSTEM
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the AM900SET! Please read the manual thoroughly before bringing this device into service. If the device was damaged in
transit, don't install or use it and contact your dealer.
2. Diagram
1. Control relay central door lock
18. 15A fuse
2. Red
19. Actuator motor rear door
3. Black
20. Actuator motor rear door
4. Blue
21. Blue
5. Green
22. Green
6. White
23. Blue
7. Brown
24. Green
8. 12V battery
25. To remote control AM6621
9. GND
26. Black
10. Actuator motor & switch – passenger side
27. White
11. Red
28. Brown
12. Black
29. Blue
13. Black
30. Green
14. White
31. Actuator motor & switch – driver’s side
15. Brown
32. Actuator motor rear door
16. Blue
33. White
17. Green
34. Brown
The information in this manual is subject to change without prior notice.
