Power-Sonic PG-2v2170 - Manual

PG Range (VRLA)
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
[email protected]
www.power-sonic.co.uk
PG-2V2170
Nominal Voltage
Nominal Capacity
2V
2140 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal T11
Approx 137.5kg
350
490
339
349
2 mm
2 mm
2 mm
2 mm +
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 542.5A
Voltage 2.4V ~ 2.5V
at 25°C (77°F)
Recommended Charge
Current less than 542.5A
Voltage 2.25V ~ 2.3V
at 25°C (77°F) 40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Rev2 03/12
3 3 9
2
3
4 9
2
490 2
3
5
0
2
0.28mΩ
(15yr Design Life in Float Service at 20ºC)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V/Time 10min 15min 20min 30min 45min 1h 2h 3h 4h 5h 6h 8h 10h 20h
1.85V/cell 2340.0 1968.0 1746.0 1448.0 1117.3 956.0 619.0 465.4 381.3 320.8 281.0 225.5 193.8 103.4
1.80V/cell 2677.5 2209.9 1930.4 1572.7 1205.3 1009.1 665.4 500.0 405.3 340.0 297.8 237.3 200.0 107.0
1.75V/cell 3041.1 2490.7 2133.3 1709.0 1314.7 1100.0 692.0 520.0 419.3 348.0 307.1 245.2 205.4 109.7
1.70V/cell 3434.6 2763.4 2354.8 1865.9 1416.0 1164.0 729.0 547.3 438.0 368.0 321.8 255.5 213.3 112.5
1.65V/cell 3688.4 2958.7 2505.1 1969.0 1498.7 1204.0 755.8 569.3 455.3 379.6 333.0 264.2 219.2 116.0
1.60V/cell \ 3240.5 2721.4 2101.1 1557.3 1240.0 775.0 584.0 465.4 388.8 340.0 268.8 223.8 117.9
Constant Current Discharge (Amperes) at 25 °C (77°F )
F.V/Time 10min 15min 20min 30min 45min 1h 2h 3h 4h 5h 6h 8h 10h 20h
1.85V/cell 4369.2 3711.6 3326.1 2788.8 2170.1 1863.1 1214.5 916.5 753.1 635.3 558.1 449.7 387.4 206.9
1.80V/cell 4941.3 4112.5 3623.9 2983.2 2322.9 1956.3 1296.9 979.1 796.2 670.2 589.0 471.8 399.2 213.8
1.75V/cell 5523.2 4578.7 3966.9 3215.2 2509.7 2122.8 1343.7 1014.3 820.9 683.7 605.5 486.5 409.4 218.9
1.70V/cell 6098.1 5010.0 4346.2 3491.1 2693.2 2239.2 1412.7 1065.7 856.0 721.8 633.6 506.5 424.9 224.4
1.65V/cell 6489.3 5323.3 4589.4 3654.2 2825.0 2299.6 1456.1 1103.8 886.5 742.0 653.7 522.3 436.1 231.1
1.60V/cell \ 5735.1 4932.0 3872.3 2920.0 2356.0 1486.0 1127.1 903.3 757.5 665.4 530.2 444.5 234.5
Constant Power Discharge (Watts/cell) at 25°C (77°F )
20hRate(1.80V/cell) 2140.00AH
10hRate(1.80V/cell) 2000.00AH
8hRate(1.75V/cell) 1961.00AH
5hRate(1.75V/cell) 1740.00AH
1hRate(1.60V/cell) 1240.00AH
20
M8
6
Torque 11.0 -14.7 Nm
T11 Threaded Insert 8mm Stud
