English | 15
Bosch Power Tools 1 619 P09 868 | (4.11.11)
Intended Use
The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, can al-
so be sawed.
Working ferrous metals is not permitted.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 On/Off switch
2 Lock-off button for On/Off switch
3 Auxiliary handle (insulated gripping surface)
4 Spindle lock button
5 Scale for mitre angle
6 Wing bolt for bevel-angle preselection
7 Wing bolt for parallel guide
8 Cutting mark, 45°
9 Cutting mark, 0°
10 Parallel guide
11 Retracting blade guard
12 Base plate
13 Lever for retracting blade guard
14 Sawdust ejector
15 Blade guard
16 Handle (insulated gripping surface)
17 Allen key
18 Clamping bolt with washer
19 Clamping flange
20 Saw blade*
21 Mounting flange
22 Saw spindle
23 Extraction adapter*
24 Clamping lever for cutting-depth preselection
25 Cutting-depth scale
26 Wing bolt for bevel-angle preselection
27 Set of screw clamps**
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
**Commercially available (not included in the delivery scope)
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 96 dB(A); Sound power level
107 dB(A). Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
a
h
<2.5 m/s 2 , K=1.5 m/s 2 .
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Circular Saw GKS 190
Professional
GKS 190
Professional
Article number 3 601 F23 0.0 3 601 F23 0.1
Rated power input W 1400 1400
No-load speed min -1 5500 5500
Cutting depth, max.
– for 0° bevel angle
– for 45° bevel angle
mm
mm
70
50
67
49
Spindle lock z z
Base plate dimensions mm 302 x 140 302 x 140
Saw blade diameter, max. mm 190 184
Saw blade diameter, min. mm 184 184
Blade thickness, max. mm 2.0 2.5
Mounting bore mm 30 16
Weight according to EPTA-Procedure 01/2003 kg 4.2 4.2
Protection class / II / II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
