ACR30 Reference Manual
Version 3.3 January 2009 Page 7 of 44
ACR30
3.0. Supported Card Types
The ACR30 can operate MCU card with T=0 and T=1 protocol. The table presented in Appendix A
explains which card type selection value must be specified for the various card types supported by the
reader.
3.1. Memory-based smart cards (synchronous interface) (*)
ƒ '104' type EEPROM non-reloadable token counter cards, including:
Gemplus GPM103,
Siemens SLE 4406
Siemens SLE4436 and SLE5536 (firmware 2.10 onwards)
ƒ Cards following the I 2
C bus protocol (free memory cards) with memory capacity up to 16 Kbit and
minimum 4 bytes page write capability, including:
Atmel AT24C01/02/04/08/16
Gemplus GFM2K, GFM4K
SGS-Thomson ST14C02C,14C04C
ƒ Siemens SLE4432/4442 intelligent 256 bytes EEPROM with write protect function:
SLE 4432, SLE 4442
ƒ Siemens SLE 4418/4428 intelligent 1K bytes EEPROM with write-protect function:
SLE 4418, SLE 4428
N OTE (*) – SAM R EADER DOES NOT SUPPORT FOR MEMORY - BASED SMART CARD
3.2. Microcontroller-based smart cards (asynchronous interface)
The ACR30 supports EEPROM microcontroller-based cards with internal programming voltage (VPP)
generation and the following programming parameters transmitted in the ATR:
PI1 = 0 or 5
I = 25 or 50
The ACR30 performs the Protocol and Parameters Selection (PPS) procedure as specified in
ISO7816-3:1997.
When the card ATR indicates the specific operation mode (TA
2
present; bit b5 of TA
2
must be 0) and
that particular mode is not supported by the ACR30, the reader will reset the card to set it to
negotiable mode. If the card cannot be set to negotiable mode, the reader will reject the card.
When the card ATR indicates the negotiable mode (TA
2
not present) and communication parameters
other than the default parameters, the ACR30 will execute the PPS and try to use the communication
parameters that the card suggested in its ATR. If the card does not accept the PPS, the reader will
use the default parameters (F=372, D=1).
For the meaning of the aforementioned parameters, please refer to ISO7816, part 3.
