DISPLAY MODES

• step: STEP mode shows your step count

since last reset, up to 100,000 steps.

• mi: DISTANCE mode shows distance

walked or jogged since last reset.

• kcal: CALORIE mode shows calories

burned through step activity

since last reset.

• AM/PM: CLOCK mode shows time

of day.

• ACTIVITY TIMER MODE shows total

activity time in minutes and seconds since last reset. The timer

runs automatically whenever steps are being recorded.

SETTING UP YOUR PEDOMETER

To record your distance and calories accurately,

you will need to set your stride length and body

weight.

Finding Your Stride Length: Your stride length is the

length of one of your steps, measured from “toe to

toe.” To measure, walk 10 steps with your normal

stride and measure the TOTAL DISTANCE from the

toe of your starting step to the toe of your 10

th

step

(see diagram below). Divide the TOTAL DISTANCE

by 10, and multiply the decimal portion by 12 to find

your stride length in feet and inches. Example: If

you walk 23 feet in 10 steps, your stride length is

2.3 feet. Multiply 0.3 x 12 = 4. Your stride length is 2

feet, 4 inches.

Setting Your Stride Length: Repeatedly press the red

MODE button until “mi” appears. Press the blue SET

button once to enter setting mode. Display will shift

to show stride, in feet and inches. Press and hold

down the blue SET button to increase stride length.

Press the red MODE button to exit setting mode.

Note: Pressing the white RESET button resets

stride length to 2' 0".

Setting Your Weight: Repeatedly press the red

MODE button until “kcal” appears. Press the blue

SET button once to enter setting mode, then press

and hold the blue SET button to increase weight

(in pounds). Press the red MODE button to exit

setting mode.

Note: Pressing the white RESET button resets

weight to 120 lbs.

Setting the Clock: Repeatedly press the red MODE

button until “AM” or “PM” appears. Press the

white RESET button. The dash will stop flashing.

Press and hold down the red MODE button until

the correct hour is displayed; release button. Press

and hold down the blue SET button until the correct

minutes are displayed; release button. Press the

white RESET button to exit setting mode. The dash

will begin flashing. The clock is now set.

Adjusting your Pedometer’s Measurement
Sensitivity
AE1700 pedometers are highly

accurate step counters. However, some walkers

may find that their step counts tend to be a bit too

high, or too low. All AE1700 models come with a

sensitivity adjustment, to help account for individual

differences. The adjustment switch has three

positions: “+,” “-,” and center. The adjustment

switch is located on the bottom of the pedometer, on

the right-hand side when looking from the front.

Adjustment Procedure: Take 100 steps, then check

STEPS display to see how many steps were actually

counted. Repeat once to make sure results are

about the same. If the pedometer counts fewer

steps than you actually walked, slide the sensitivity

adjustment towards the “+” icon. This will increase

recorded steps by about 10%. If the pedometer

counts more steps than you actually walked, slide

the sensitivity adjustment towards the “-” icon. This

will decrease recorded steps by about 10%.

WEARING YOUR PEDOMETER

While gently holding the belt clip open, slide the

pedometer onto your belt or the top edge of your

pants or skirt. It should fit snugly and level, above

one knee.

Note: The pedometer should be as vertical as

possible. Walkers with larger stomachs may find it

helpful to wear the pedometer farther back on the

body, toward one hip.
The cover must be closed for the pedometer to
work.
To avoid losing or dropping your pedometer,

use the included leash and clip to fasten the

pedometer securely to your clothing.

ACCUSPLIT AE1790 Pedometer

INSTRUCTIONS

ACCUSPLIT, Inc. • 2290M Ringwood Ave. • San Jose, CA 95131

800-965-2008 • 925-226-0888 • FAX 925-463-0147 • www.ACCUSPLIT.com • [email protected]

Attaching the Leash: Attach the pedometer to the

leash by looping the leash through the pedometer

leash slot. Next, loop the leash through the metal

clip. Finally, clasp the waistband of your clothing

with the metal clip. You can also use a safety pin

to fasten the leash to your clothing, loop the leash

through your belt or belt loop, or use a badge holder.

VIEWING YOUR RESULTS

Once you put on your pedometer with the cover

closed, it will automatically begin to record your

steps, distance, calories burned, and activity time.

Repeatedly press the red MODE button to cycle

through the pedometer modes:

STEP → DISTANCE → CALORIE → CLOCK →

ACTIVITY TIMER → STEP

RESETTING YOUR PEDOMETER

Most people prefer to reset step, distance, and

calorie counts daily. To reset: From STEP, DISTANCE,

or CALORIE mode, press and hold the white RESET

button for at least 2 seconds.

REPLACING THE BATTERY

When the display starts to dim or goes blank, it is

time to replace the battery. Your pedometer uses

one Type L1142 (LR43) 1.5 volt silver oxide battery.

To replace:

1. Insert a coin into the slot on the front of the

case, and twist counterclockwise to loosen

the battery door.
2. Remove battery door and take out the old

battery. Replace it with a new battery. The

battery’s positive (+) terminal should be

FACE UP while you put it into the pedometer.
3. Put the battery door back on and twist the

coin clockwise to tighten.

Eat Right! Walk More! Live Well!

The ACCUSPLIT Lifestyle

Congratulations on taking the first step to wellness

with your purchase of an ACCUSPLIT pedometer.

It’s easy to set up your new pedometer.

Just follow the steps below, and start walking!

Red:

MODE

9789

Blue:

SET

White:

RESET

10 steps

970-053

First, loop the

pedometer leash slot

Next, loop the metal

clip, then clasp clothing

Or, loop a

badge holder,

then put into pocket

(Badge holder

not included)

Or, loop a belt or belt loop
