❒ refit the bulb holder;
❒ reconnect the electric connector, correctly realign the
unit with the car body and then tighten the fastening
screws A.
IMPORTANT To replace the LED taillights you must con-
tact a Fiat Dealership.
REAR FOG LIGHTS fig. 176
Contact a Fiat Dealership to have bulbs for the rear fog
lights A replaced.
REVERSE LIGHTS fig. 176
Contact a Fiat Dealership to have bulbs for the reverse
lights B replaced.
F0U0157m fig. 176 F0U0281m fig. 177
THIRD BRAKE LIGHT fig. 177
To change the bulb proceed as follows:
❒ open the boot;
❒ remove the rubber caps;
❒ press in the catches and remove the lens unit
C-fig. 177;
❒ disconnect the electric connector;
❒ press in the tabs D-fig. 177 and remove the bulb holder;
❒ remove the snap-fitted bulb and replace it.
NUMBER PLATE LIGHTS
To change the bulb proceed as follows:
❒ manipulate the point shown by the arrow and remove
the lens unit A-fig. 178;
