1 4XM-2582T-00-00 DISC, BRAKE . . . . . . . . . . . . . 1
2 90149-06272-00 SCREW . . . . . . . . . . . . . . . . . . 6
3 5DH-2580T-00-00 CALIPER ASSY (LEFT) . . . . . . 1
4 4EW-W0057-00-00 . PISTON ASSY, CALIPER . . . . 1
5 3JD-W0047-00-00 . . CALIPER SEAL KIT . . . . . . . 1
6 5DH-25919-00-00 . SUPPORT, PAD . . . . . . . . . . . 1
7 1UY-W0048-50-00 . BLEED SCREW KIT . . . . . . . . 1
8 5DH-W0045-00-00 . BRAKE PAD KIT . . . . . . . . . . 1
9 5DH-25933-00-00 . PIN, PAD . . . . . . . . . . . . . . . . 1
10 5DH-25916-00-00 . PLUG . . . . . . . . . . . . . . . . . . . 1
11 90105-08659-00 BOLT, WASHER BASED . . . . . 2
12 5DH-2314E-00-00 COVER, HOSE . . . . . . . . . . . . . 1
13 95827-06012-00 BOLT, FLANGE . . . . . . . . . . . . 1
14 95027-08020-00 BOLT, FLANGE . . . . . . . . . . . . 1
15 5DH-25875-00-00 HOLDER, BRAKE HOSE 1 . . . . 1
16 92907-08200-00 WASHER . . . . . . . . . . . . . . . . . 1
FRONT BRAKE CALIPER
Ref. Part
No. Number Description Qty Remarks
C11
YZ125K1
