SOLVING PROBLEMS
Clearing area 2A
Lift the green handle. Remove and discard any paper you find in
this area.
Clearing areas 3 through 5
When paper jams occur in areas 3 through 5, three extra blank
sheets are sent through the printer to make sure that the fuser is
clean. These sheets are sent to an unused stacker tray and
should be discarded. You are not charged for these sheets. If
the job is directed into stacker tray 1 or 2, the discarded copies
are sent to the sample tray. If the job is directed to the sample
tray, discard copies are sent to an empty stacker tray.
Follow these steps to clear area 3:
1. Push and hold the green handle to the right (in the direction
of the arrow marked on it).
2. Remove and discard any paper found there.
3. Release the handle and close the door.
XEROX 4050/4090/4450/4650 LPS OPERATOR GUIDE 8-7
