Zebra Technologies GX420T User Manual
Page 89
77
Maintenance
Replacing the Printhead
12/14/07
GX420t / GX430t User Guide
980612-001 Rev. A
5.
Insert the printhead bracket’s the tab into slot in the ribbon frame assembly. Align the
printhead spring slots to the five posts and snap the printhead into the ribbon frame.
Slot
Post
Spring
Slot
Tab
Spring
Slot
Spring
Post
