Zebra Z4M/Z6M Printers User’s Guide 21
)URQW 3DQHO /LJKWV
Light Status Indication
POWER Off The printer is off or no power is applied.
On The printer is on.
PAUSE
Off Normal printer operation.
On The printer has stopped all printing operations.
Flashing In peel-off mode, the PAUSE light flashes when the label is
available for removal, and when initializing FLASH or PCMCIA
memory.
ERROR
Off Normal printer operation (no errors).
Slow flashing “RIBBON IN” warning, “HEAD UNDER TEMP” warning, or “HEAD
OVER TEMP” error.
Fast flashing “HEAD OPEN” error.
On “PAPER OUT”, “RIBBON OUT”, or “CUTTER JAM” errors.
DATA
Off Normal printer operation (no data being received or processed).
One flash The CANCEL key is pressed and a format is successfully cancelled.
Slow flashing The printer is unable to accept more data from the host.
Fast flashing The printer is receiving data.
On A partial format has been received and there has been no
subsequent data activity.
