Before Getting Started
This guide will help you properly install Wilson’s dual-band, mobile wireless amplifi er. It is
important to read through all of the installation steps for your particular application
prior to installing any equipment. Read through the instructions, visualize where all the
equipment will need to be installed and do a soft installation before mounting any equipment.
If you do not understand the instructions in full, seek professional help, or contact Wilson
Technical Support at 866-294-1660.
Warning: In a wireless installation,
do not plug the amplifi er directly into the
cell phone or data card using an antenna
adapter. It will damage the amplifi er.
!
Outside
Antenna
Inside
Antenna
Amplifi er
DC Power
Supply
Cell Phone
PDA
Notebook
Installation Diagram
